Investigation of the indium effect on the structural, optical and wettability characteristics of SnO₂ thin films prepared by rapid thermal evaporation
DOI:
https://doi.org/10.31349/RevMexFis.72.031003Keywords:
SnO2-In thin films, Rapid thermal evaporation, XRD, optical properties, HydrophilicityAbstract
While indium (In) doping of tin oxide (SnO2) has been extensively explored for its structural, optical, and electrical properties, its combined effect on surface wettability and multifunctional performance remains largely unexplored. In this study, indium-doped SnO2 thin films were synthesized via rapid thermal evaporation, and their structural, morphological, optical, electrical, and wettability properties were systematically correlated. Both undoped and In-doped films were deposited on glass and silicon substrates. X-ray diffraction (XRD) confirmed the formation of polycrystalline SnO2 with a dominant tetragonal phase in both undoped and doped samples, while atomic force microscopy (AFM) revealed a significant reduction in surface roughness from 9.6 nm for undoped films to 3.6 nm upon incorporation of 5 wt.% indium. Optical transmission measurements, carried out using a UV-Vis spectrophotometer showed enhanced optical transparency with indium incorporation, reaching over 86% at 5 wt.% In and remaining around 80% for higher doping levels (10-15 wt.%). The optical band gap exhibited minor variations with doping, initially increasing from 3.80 eV (undoped) to 3.81 eV (5 wt. %), then slightly decreasing to 3.78 eV (10 wt. %), and rising again at 15 wt. % indium, reflecting tunable optoelectronic behavior. Four-point probe measurements demonstrated a decrease in resistivity with increasing indium content. Contact angle measurements using a surface tensiometer showed that all films displayed hydrophilic surfaces.
Downloads
References
A.Salehi and M. Gholizade, Gas-sensing properties of indiumdoped sno2 thin films with variations in indium concentration, Sensors and Actuators B: Chemical, 89 (2003) 173 DOI: https://doi.org/10.1016/S0925-4005(02)00460-4
S. Maadadi et al., Investigation of optical, dielectric, and electrical properties of zno/cold sprayed al system and their correlation with photovoltaic performance: S. maadadi et al. Optical and Quantum Electronics 57 (2025) 345 DOI: https://doi.org/10.1007/s11082-025-08266-1
W. Ke et al., Low-temperature solution-processed tin oxide as an alternative electron transporting layer for efficient perovskite solar cells, Journal of the American Chemical Society, 137 (2015) 6730 DOI: https://doi.org/10.1021/jacs.5b01994
P. Liu and V. Sivakov, Tin/tin oxide nanostructures : Formation, application, and atomic and electronic structure peculiarities, Nanomaterials, 13 (2023) 2391 DOI: https://doi.org/10.3390/nano13172391
A. A. Ahmad, A. Migdadi, and Q. M. Al-Bataineh, Structural, optical, and electrical properties of strontium-doped tin dioxide films for high photoconductivity, Thin Solid Films, 796 (2024) 140312 DOI: https://doi.org/10.1016/j.tsf.2024.140312
D. Sharma et al., Crystal chemistry and physicochemical investigation of aliovalent substituted sno2 nanoparticles, Vacuum, 184 (2021) 109925 DOI: https://doi.org/10.1016/j.vacuum.2020.109925
S. Sujatha Lekshmy and K. Joy, Structural and optoelectronic properties of indium doped sno2 thin films deposited by sol gel technique, Journal of Materials Science: Materials in Electronics, 25 (2014) 1664 DOI: https://doi.org/10.1007/s10854-014-1781-x
M. A. Abdulsattar, S. S. Batros, and A. J. Addie, Indium doped sno2 nanostructures preparation and properties supported by dft study, Superlattices and Microstructures, 100 (2016) 342 DOI: https://doi.org/10.1016/j.spmi.2016.09.042
S. Laghrib, M. Benhaliliba, H. Adnani, and D. Abdi, Wide bandgap indium-doped sno2 semiconductor prepared by solgel route: Multilayer fabrication and low resistivity for solar cell application, Journal of Sol-Gel Science and Technology, 106 (2023) 530 DOI: https://doi.org/10.1007/s10971-023-06093-y
H. Kang, Y. Xiong, L. Ma, T. Yang, and X. Xu, Recent advances in micro-/nanostructure array integrated microfluidic devices for efficient separation of circulating tumor cells, RSC advances, 12 (2022) 892 DOI: https://doi.org/10.1039/D2RA06339E
F. Lekoui et al., Ag-doped zno nanostructured thin films for transparent antibacterial surfaces: Effect of ag content, Inorganic Chemistry Communications, 173 (2025) 113831 DOI: https://doi.org/10.1016/j.inoche.2024.113831
B. Cojocaru, D. Avram, V. Kessler, V. Parvulescu, G. Seisenbaeva, and C. Tiseanu, Nanoscale insights into doping behavior, particle size and surface effects in trivalent metal doped sno2, Scientific reports, 7 (2017) 9598 DOI: https://doi.org/10.1038/s41598-017-09026-2
Z. Ji, L. Zhao, Z. He, Q. Zhou, and C. Chen, Transparent p-type conducting indium-doped sno2 thin films deposited by spray pyrolysis, Materials Letters, 60 (2006) 1387 DOI: https://doi.org/10.1016/j.matlet.2005.11.057
B. Alemayehu, E. Shin, V. Vasilyev, and G. Subramanyam, Synthesis and characterization of indium-doped sno2-based impedance spectroscopy sensor for real-time humidity sensing applications, Crystals, 14 (2024) 82 DOI: https://doi.org/10.3390/cryst14010082
S. SujathaLekshmy, L. Maneeshya, P. Thomas, and K. Joy, Intense uv photoluminescence emission at room temperature in sno2 thin films, Indian Journal of Physics, 87 (2013) 33 DOI: https://doi.org/10.1007/s12648-012-0199-7
A. Hafdallah, F. Ynineb, M. Aida, and N. Attaf, In doped zno thin films, Journal of Alloys and Compounds, 509 (2011) 7267 DOI: https://doi.org/10.1016/j.jallcom.2011.04.058
D. Dergham, S. Hassani, F. Lekoui, M. Ouchabane, R. H. Ali, and I. Djemai, Optimisation of optical and electrical properties of zno/au-pd/zno multilayer thin films, in 2022 2nd International Conference on Advanced Electrical Engineering (ICAEE). IEEE, 2022), pp. 1-4 DOI: https://doi.org/10.1109/ICAEE53772.2022.9962040
F. Ynineb, A. Hafdallah, N. Attaf, M. S. Aida, J. Bougdira, and H. Rinnert, Microstructure and opto-electrical properties of sno2: In2o3 alloys thin films prepared by ultrasonic spray, International Journal of Nanoparticles 11 (2013) 252 DOI: https://doi.org/10.1504/IJNP.2013.055001
B. Teldja, B. Noureddine, B. Azzeddine, and T. Meriem, Effect of indium doping on the uv photoluminescence emission, structural, electrical and optical properties of spin-coating deposited sno2 thin films, Optik, 209 (2020) 164586 DOI: https://doi.org/10.1016/j.ijleo.2020.164586
M. M. Rahaman, K. M. A. Hussain, M. Sharmin, C. Das, and S. Choudhury, Structure, morphology and opto-electrical properties of nanostructured indium doped sno2 thin films deposited by thermal evaporation, European Scientific Journal, ESJ, 12 (2016) DOI: https://doi.org/10.19044/esj.2016.v12n27p263
F. Lekoui et al., Elaboration and characterization of pure zno, ag : Zno and ag-fe : Zno thin films : Effect of ag and ag-fe doping on zno physical properties, Rev. Mex. Fis. 69 (2023) 0 DOI: https://doi.org/10.31349/RevMexFis.69.051005
D. Grine et al., Synthesis, characterization, and antibacterial activity of ag-tio2-fe composite thin films, Physica Status Solidi (a), 219 (2022) 2200036 DOI: https://doi.org/10.1002/pssa.202200036
M. Okuya, S. Kaneko, K. Hiroshima, I. Yagi, and K. Murakami, Low temperature deposition of sno2 thin films as transparent electrodes by spray pyrolysis of tetra-n-butyltin (iv), Journal of the European Ceramic Society, 21 (2001) 2099 DOI: https://doi.org/10.1016/S0955-2219(01)00180-7
W. Zhou, Y. Liu, Y. Yang, and P. Wu, Band gap engineering of sno2 by epitaxial strain : experimental and theoretical investigations, The Journal of Physical Chemistry C, 118, (2014) 6448 DOI: https://doi.org/10.1021/jp500546r
F. Lekoui et al., Investigation of annealing environment effect on the structural, morphological, and linear/nonlinear optical properties of nanostructured mn-doped zno thin films, Inorganic Chemistry Communications, 176 (2025) 114209 DOI: https://doi.org/10.1016/j.inoche.2025.114209
B. Thangaraju, Structural and electrical studies on highly conducting spray deposited fluorine and antimony doped sno2 thin films from sncl2 precursor, Thin solid films, 402 (2002) 71 DOI: https://doi.org/10.1016/S0040-6090(01)01667-4
A. Munshi, V. Singh, M. Kumar, and J. Singh, Effect of nanoparticle size on sessile droplet contact angle, Journal of Applied Physics, 103 (2008) 13 DOI: https://doi.org/10.1063/1.2912464
R. Amrani et al., Structural and optical properties of highly ag-doped tio2 thin films prepared by flash thermal evaporation, Physica Scripta, 99 (2024) 065914 DOI: https://doi.org/10.1088/1402-4896/ad4014
Y. Wang, H. Zhang, X. Zhang, Z. Zhou, and L. Wang, Tuning electrical and optical properties of sno2 thin films by dualdoping al and sb, Coatings, 15 (2025) 669 DOI: https://doi.org/10.3390/coatings15060669
M. Caglar and K. C. Atar, Effect of both deposition temperature and indium doping on the properties of sol-gel dip-coated sno2 films, Spectrochimica Acta Part A : Molecular and Biomolecular Spectroscopy, 96 (2012) 882 DOI: https://doi.org/10.1016/j.saa.2012.07.108
G. Bhatia, A. D. Acharya, M. Patidar, V. Gupta, S. Shrivastava, and V. Ganesan, Tuning of structural, morphological, optical and electrical properties of sno2 by indium inclusion, Bulletin of Materials Science, 44 (2021) 187 DOI: https://doi.org/10.1007/s12034-021-02449-8
R. S. Zeferino, U. Pal, M. E. D. A. Reues, and E. R. Rosas, Indium doping induced defect structure evolution and photocatalytic activity of hydrothermally grown small sno 2 nanoparticles, Advances in nano research, 7 (2019) 13
G. Zhou, S. Ni, X. Sun, X. Wang, Q. Wang, and D. He, Visible photoluminescence of hydrothermal synthesized sn1- x ni x o2 nanostructures, Journal of Materials Science: Materials in Electronics, 22 (2011) 174 DOI: https://doi.org/10.1007/s10854-010-0109-8
J. Jeong et al., Photoluminescence properties of sno2 thin films grown by thermal cvd, Solid State Communications, 127 (2003) 595 DOI: https://doi.org/10.1016/S0038-1098(03)00614-8
Y. Du, M.-S. Zhang, J. Hong, Y. Shen, Q. Chen, and Z. Yin, Structural and optical properties of nanophase zinc oxide, Applied Physics A, 76 (2003) 171 DOI: https://doi.org/10.1007/s003390201404
